Panorax 35-ZI



Panorax Optical Ind. Co., Tokyo.

Teikoku Tsushin Ind. Co., Kawasaki Japan.

Panoramic camera,



no. 406, for 45° to 350° exposures on film 135.
With instructions, 3 mirror viewfinders and original leather case.
 Extremely rare and of outstanding technical interest!



Year:  1958



Working Schematics

Top periscope viewfinder four image former

Periscope viewfinder

Viewfinder image with bubble level in the center

Lens and mirror in taking position. Viewfinder off.

Lens detail

Folded set

Bottom view

xxxxxxxxxxxxxxxxxxxxxxxxxx



Back
